ENGLISHProduct Overview
AbleTech Wireless Talking Rear Detector provides clear picture quality for the driver to ensure visibility and complete monitoring of the surrounding when driving a vehicle. The strong durability guarantees a stable rear image even in roughoutside work environments.
To become one of technology leaders in wireless rear camera industry, Abletech developed a product with following feature.
The RUSS1000E Rear Detector boasts brighter colorscompared to other competing products, and it is resistant to corrosion becauseit is made of zinc. Therefore, it can be used for a long time without being influenced by external environment.
Product Specifications
| Item | RUSS1000E |
|---|---|
| Working Voltage | 12V,24V(+7V~ +40V) |
| Power consumption | 1W MAX(max.150mA) |
| Operating temperature | -30˚~+70˚ |
| Sensing distance | 30cm ~ 2M(basic) ~ maximum 5M(OPTION) |
| Channel used | Basic 2CH, (option3~4cH) |
| Alarm display | Basic 2 LAMP RED LAMP Indicator |
| Voice alarm | 1W (Volume control) |
| RF Frequency | 443MHz or 447.275MHz |
| RF Output | 10mW(+10dBm ) max. |
| Modulation | FM FSK-OOK |
Download
| Classification | File | Last modified date |
|---|---|---|
| Product Specification | 0000-00-00 | |
| Manual | 0000-00-00 | |
| CAD | 0000-00-00 | |
| Test report | 0000-00-00 | |
| Product certificate | 0000-00-00 |
