RCS4000R

Producing firm and clear rear camera
is protecting the worker.


  • 상품간략정보 및 구매기능


    Installation possible vehicle 트럭,버스,특장차,승합,승용차
    Connection wire 무선
    Certification KC
    Used voltage 12V / 24V 겸용
    Pixel 200만화소
    Viewing angle 155도
    Waterproof I

    Product Overview

    Abletech rear camera provides clear picture quality for the driver to ensure visibility and complete monitoring of the surrounding when driving a vehicle. The strong durability guarantees a stable rear image even in roughoutside work environments.


    The Abletec wireless monitor rear-view camera offers clear picture quality to ensure driver's visibility and monitoring, and provides a stable rear view with rugged durability even in harsh outdoor work environments. To become one of the technology leaders in the field of wireless front and rear cameras, AbleTech has developed the following features.


    The RCS4000R wireless rear-view camera boasts more color than competing products, and the enclosure is made of zinc and is resistant to corrosion. Therefore, it can be used for a long time without being influenced by external environment.


    Beyond offering easy installation and good mobility, it is applied with the technology which prevents screen interruption and wireless interference when in use, thereby offering high stability.

    It offers wireless communication to the distance over 100 meters, automatic connection between transmitting camera and receiving monitor by using individual ID after registering PIN ID.


    When installed in the camper trailer in white color, it is also nice to look at.


    · Screen resolution: produce bright screen with high resolution of 52,000 pixels

    · Viewing angle: features excellent viewing angle of 155 degrees.

    · Enclosure material: boasts long life of more than 10 years because it is made of zinc material which offers strong resistance to corrosion.

    · orean Product: Abletech, who have acquired the patented technology, supplies the product after producing in Korea.

    Product Specifications

    ITEM RCS 4000R
    Image Sensor 1/3” SONY & SHARP SUPER CCD, [ High Sensitivity ] 52K Pixels ( Opt. 41k/27k )
    Effective Pixel [ H ] 510 x [ V ] 492 [ NTSC ] / [ H ] 500 x [ V ] 582 [ PAL ]
    Scanning System 2:1 Interlacing / 525 Lines [ NTSC ], 625 Lines [ PAL ]
    Sync. System Internal Sync
    Scanning Frequency NTSC : [ H ] 15.734 KHz x [ V ] 59.94 Hz
    PAL : [ H ] 15.625 KHz x [ V ] 50 Hz
    Horizontal Resolution More Than 380 TV Lines
    Video Output VBS 1.0 Vp-p ± 10% / 75Ω
    S/N Ratio 50 dB Min [ ACC off, Y signal ]
    Min. Illumination 0.1 Lux at F 2.0 AGC ON
    Lens f-2.9mm, View 155˚ [ Dia. ] ( Opt. 120˚ )
    Gain Control Autormalic Gain Control
    Gamma 0.45
    Shutter Speed Electronic Auto Iris
    1/50 ~ 1/100,000 : PAL/1/60 ~ 1/100,000 : NTSC
    Input Voltage DC 9V - 30V [ DC 12V, 150mA MAX ]
    Ambient Temperature - 20˚C ~ 70˚C, 85% RH
    Mirror ON / OFF
    BLC YES
    IR LED 850nm IR LEDs 5EA / CDS Sensor 1EA
    Night View Distance Outdoor 15m ~
    MIC 44dB( Opt. )
    Housing Color Black, Silver
    Connector S-Pin Din, 5.5mm Dc Jack, RCA(m)
    Weight Approx, 474g
    IP Resistance Certified IP 67 Level
    Approval CE, FCC, e-mark
